Transmission temperature on 2019 Ford Expedition goes up to 107C (225F) in winter during normal drive and not towing. Is it normal?

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

Azureo81

Member
Joined
Oct 12, 2023
Posts
13
Reaction score
8
Location
Ontario, Canada
The transmission temperature on a 2019 Ford Expedition goes up to 107C (225F) in winter during normal drive and not towing. Is it normal? Also the radiator fan goes on, every few minutes. Again, it is winter where I live and there is no crazy driving/towing involved. The dealer says it is normal for what I mentioned above. I would like to hear your opinions. Is it time to visit another mechanic?


Attachments

  • IMG_3807.jpeg
    169.8 KB · Views: 3

99WhiteC5Coupe

Full Access Members
Joined
Jun 3, 2015
Posts
3,019
Reaction score
1,664
Location
USA
The transmission temperature on a 2019 Ford Expedition goes up to 107C (225F) in winter during normal drive and not towing. Is it normal? Also the radiator fan goes on, every few minutes. Again, it is winter where I live and there is no crazy driving/towing involved. The dealer says it is normal for what I mentioned above. I would like to hear your opinions. Is it time to visit another mechanic?



I do not believe those temperatures are normal.

Have you checked your engine coolant - to see if the engine coolant level is low (which would explain the radiator fan turning on and off)?

OP
OP
A

Azureo81

Member
Joined
Oct 12, 2023
Posts
13
Reaction score
8
Location
Ontario, Canada
I do not believe those temperatures are normal.

Have you checked your engine coolant - to see if the engine coolant level is low (which would explain the radiator fan turning on and off)?
Yes, the coolant is fine. I’m suspecting clogged radiator, or something else. I don’t believe the dealer on it. Also the gearbox temperature looks much too high. They say it is normal.


apex96

Full Access Members
Joined
Jul 11, 2021
Posts
337
Reaction score
241
Location
PA
Sounds like a failing thermostat. The temps isn't far off what would be considered normal though. With colder conditions the vehicle wants to keep the grill shutters closed to prevent rapid fluctuations in temps as the hot fluid enters the cold radiator, keeping wind driven cold air from passing through helps smooth out the temp curve and prevents the vehicle from constantly opening and closing the shutters. The PCM is taking coolant temps and ambient temps into consideration when it commands fan and shutters to operate.

I do feel that the 212 temp that activates the electric fans is way to high. I would have a custom tune made and have the tuner lower the engagement temp for the fan. mine is now set to turn fans on around 196/195 and the shutters are always in the full open position now.


Calidad

Full Access Members
Joined
Oct 1, 2019
Posts
672
Reaction score
339
Location
California
Literally just replaced my faulty thermostat last week on my 19. It progressively gets worse over time affecting transmission temperature and eventually popping up coolant temp at 228+ F

190-201 F seems to be normal low load transmission temps with the updated thermostat. I haven’t towed yet but will report back. Probably Mid/late April.

230 is hot 240-260 is pull over and get it cooled off temp.

Fan kicks on around 210-212

OP
OP
A

Azureo81

Member
Joined
Oct 12, 2023
Posts
13
Reaction score
8
Location
Ontario, Canada
Literally just replaced my faulty thermostat last week on my 19. It progressively gets worse over time affecting transmission temperature and eventually popping up coolant temp at 228+ F

190-201 F seems to be normal low load transmission temps with the updated thermostat. I haven’t towed yet but will report back. Probably Mid/late April.

230 is hot 240-260 is pull over and get it cooled off temp.

Fan kicks on around 210-212
Appreciate your feedback. I will most likely replace the termostat and see if this helps. I’m just surprised that the dealer did not flag it to me.

OP
OP
A

Azureo81

Member
Joined
Oct 12, 2023
Posts
13
Reaction score
8
Location
Ontario, Canada
Sounds like a failing thermostat. The temps isn't far off what would be considered normal though. With colder conditions the vehicle wants to keep the grill shutters closed to prevent rapid fluctuations in temps as the hot fluid enters the cold radiator, keeping wind driven cold air from passing through helps smooth out the temp curve and prevents the vehicle from constantly opening and closing the shutters. The PCM is taking coolant temps and ambient temps into consideration when it commands fan and shutters to operate.

I do feel that the 212 temp that activates the electric fans is way to high. I would have a custom tune made and have the tuner lower the engagement temp for the fan. mine is now set to turn fans on around 196/195 and the shutters are always in the full open position now.
Thank you for your point of view. I will replace the termostat as few of you pointed it to me as the cause.


Calidad

Full Access Members
Joined
Oct 1, 2019
Posts
672
Reaction score
339
Location
California
Just did a 98 mile 2 directions errand. All highway 70-75mph light traffic 60F outside. Transmission ran 183-185 while moving. Pulling off the highway 187-190 was the high peak while in stopped traffic.

One climb from 100ft to 2000ft at 70mph temp ran 185 the whole climb.
Definitely running cooler and far more consistent temp.
Will be towing heavy mid to end of April and will report back

Anyone running a 2018-2022 seeing 210-212 transmission temps in mild low stress conditions just get the $40 updated thermostat done. Its a 1hr shop time service. Run the numbers and be ready to call BS on anyone charging more than $190 hr shop rate

OP
OP
A

Azureo81

Member
Joined
Oct 12, 2023
Posts
13
Reaction score
8
Location
Ontario, Canada
Ford service isn’t cheap, but what makes me upset is that I brought up the issue and they did not take care of it. They just disregarded it saying it is normal. I’m going to another dealer hoping they can take my observations seriously and fix the issues


Calidad

Full Access Members
Joined
Oct 1, 2019
Posts
672
Reaction score
339
Location
California
Ford service isn’t cheap, but what makes me upset is that I brought up the issue and they did not take care of it. They just disregarded it saying it is normal. I’m going to another dealer hoping they can take my observations seriously and fix the issues
Mind did the same. I had them work up cost to replace it anyway. Then said no thanks its a 1hour shop job $190hr shop rate and a $40 part. They quoted me $850!! I laughed said no I’ll pick it up have someone else do the fix then I would file a claim against the dealer.

Oh!! Your a premium member I didn’t see that you have $100 deductible and we’ll have it done shortly. Hmm? WTF? That was 4th phone call. Service manager was trying to pump me for a lottery win. By the way that’s standard operating procedure for all dealers
