Show your Lifted 3rd Gens

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

No_Fish1978

New Member
Joined
Mar 9, 2019
Posts
3
Reaction score
0
Location
Oklahoma
I'm new....first post. Been searching all weekend but can't find confirmation.
Looking at the ReadyLift 3/2 for my '17 EL Limited with power boards. Factory 22" x 9.5" +44mm wheel, 285/45/r22 Scorpions.

If I have a 20x9 +30mm wheel picked out....will a 275/65 r20 BFG AT that is 34.1" tall (2" taller than stock) and 10.8" wide(.4" narrower than stock) fit without rubbing after the ReadyLift kit? Any other issues I should be worried about?

Sent from my SM-N960U1 using Tapatalk


Eric B

Member
Joined
Nov 9, 2018
Posts
15
Reaction score
1
Location
waukesha
I want to bring up the front just to level it off. Would you do 1.5 or 2.0 inch? Supreme
Suspension any good? They were decently priced. Thanks.


Adventure Driven

Full Access Members
Joined
Oct 26, 2016
Posts
51
Reaction score
60
Location
Flagstaff
Nice! What is replacing him? Specs for those that might be interested? Website link?


Sent from my iPhone using Tapatalk Pro


Cool, thanks, here is where to learn more



https://www.facebook.com/adventuredriven/posts/2249123848685933?__tn__=K-R

http://www.adventuredriven.com/

https://www.instagram.com/adv_driven/?hl=en

Here are the specs:

2007 Ford Expedition 4x4 5.4 L V-8 Adventure Driven’s Aspen $53,000.00 fully equipped and ready for adventure travels. 136788 miles.




The time has come to sell our one of a kind Unicorn overland truck. As far as we know the only one with this level of build in the whole wide world.



For 2019 we are going to focus our travels and adventures in our 1994 LMTV M1079 “Brutus” so Aspen our 2007 Ford Expedition will just be sitting while we are away. So we have decided to let someone else enjoy Aspen.


Aspen has proven himself on so many levels. Let’s face it, we were charging uncharted waters when we decided to build him, no one really has built an Expedition for extended comfortable travel so we were on our own. And we were not 100% certain it would even be a good choice. Well, that was worry that quickly fled. Silly side point, it does say “Expedition” on the door, we should have know it would turn out golden.



Aspen has 300HP and 365 TQ, payload capacity of 1895 pounds, (that’s more than a Toyota Tundra, to put it into perspective) and a 9000 pound towing capacity. The selectable 4 wheel drive with front and rear independent ICON Vehicle Dynamics 2.5 CDC valve one off custom suspension is a dream, very comfortable off and on road. We do not even air down all that much as it rides so good off road even on long corrugated dirt roads. Aspen has less interior cabin road noise than our GX470 Lexus, more power than our Lexus, tons more room, cheaper to insure and license, less expensive parts when needed, overall more comfortable to drive, the supportive scheel-mann seats are killer and the turning radius is the sharpest of any vehicle we have ever owned including our FZJ80 or GX470.



The truck drives great on the HWY and off road, we even took it on part of the Rubicon Trail and it surprised us with its competence.



This truck has zero rust, it has lived in the southwest its entire life.



Check out our “Adventure Driven” YouTube channel for more details and info.



Clear title comes with AZ bill of sale, No trades, cash only, not parting out so please don’t ask. Truck is located in Flagstaff AZ and can deliver personally anywhere, you pay our travel expenses.



I have personally maintained this truck meticulously in every way, only used Ford parts when available and we chose the best companies to work with to create the build. Here is a list of features and items included with the truck as priced.



VIN # 1fmfu16547LA68930



$53,000.00





Build list:



1. CBI Off Road front and rear bumpers, full skid plates and sliders; all custom one-off parts not available for purchase from CBI. We worked very close with the design and features we wanted and they totally knocked it out of the park, attention to detail is a solid A Plus. Rear bumper is a two piece swing out with drop down table for food prep, rear aluminum box for storage and a separate attached kitchen cutlery and spices space on the inside, all box’s have drop down doors. There are 2 light posts with KC cyclone LED’s on a switch. This set up makes cooking a breeze and is well thought out in terms of space and easy to use. $15,000.00



2. ICON Vehicle Dynamics suspension custom one off parts not available for purchase, consisting of : (4) 2.5 CDC valve custom sprung coil overs with front upper control arms. This has changed the truck to amaizing in every way, small bump compliance is outstanding, we rarely air down when off-road, swallows chop and stutter bumps like it is not even there, handles fantastic on the HWY as well. $8000.00



3. Scheel-Mann USA front seats on custom seat brackets so they are 100% bolt in. Lets face it the stock Ford seats were absolutely awful, after much research we called Toby at Scheel-Mann USA and ended up with a set of orthopedic Traveler LR Edition seats that are absolutely perfect, we spend long days in them and still feel fresh, they feel great, supportive in all the right spots. After a 12 hour drive day we are not sore at all, one of our favorite mods we have made to Aspen. $4600.00



4. KC HiLites, turn night into day!!!!! 3 Carbon Pods on front bumper, Flex 50 inch above windshield, 2 LZR 4 inch LED ditch lights in front bumper, 3 LZR cube reverse lights automatically activated, 6 C2 area lights on roof rack for around camp, and 2 flood Cyclone lights on rear bumper poles for cooking etc. $3998.00



5. COME-UP winch Seal 12.5 with synthetic line $1150.00



6. Factor 55 Ultra Hook with rope guard $298.00



7. Equipt Expedition Outfitters parts :

K-9 Roof rack $1230.00

Large K-9 table mounted under roof rack $320.00

Stealth Roof Top Tent $3900.00

Dual Battery controller $395.00



8. Rhino Rack awnings:

Batwing awning $700.00

Sun Seeker awning on passenger side $309.00



9. Custom 20 gallon fresh water tank installed where the factory spare tire used to be:

20 gallon water tank $80.00

CBI Custom one-off support and skid plate system $1500.00

RV 12 volt pump with the fill and sprayer mounted inside $169.00



10. Stanley Steps to climb on roof $299.00

11. Dometic CFX 100W fridge freezer $1100.00

12. (5) Falken 35x12.50R17 $1250.00

13. (5) ICON Alloys six speed wheels 5 3/8 back space, 17x8 $1210

14. (4) Action Trax Recovery Boards $470.00

15. Gas Grill BBQ $74.00 (Cooks a mean porterhouse!) :)

16. Nitro 4:45 gears with front and rear ARB air lockers and a twin ARB air compressor, air outlet mounted on rear bumper, comes with air hose and gauge, installed at Nitro Gear and Axle $3900.00

17. Custom head lights $400.00

18. Power tow mirrors $325.00

19. Front door sound proofing installed $225.00

20. Ultra Gauge scanner and engine info center $69.00

21. Custom cat back exhaust system, not loud $535.00

22. Trash-A-Roo new $40.00

23. 400 watts of rollable solar panels $2000.00

24. Victron SmartSolar MPPT 100/50 charge controller $325.85

25. ARB air hose and tire gauge $100.00

26. Window Vent Visors $79.00

27. Under hood heat exchanger for hot water shower $425.00

28. WeBoost 4G cell phone booster $499.00

29. Tekonsha brake controller $130.00

30. Noco shore 110V power port flush mount $17.00

31. Perco deck fill fresh water fill located inside $29.99

32. (2) solar power input ports, located front and rear to plug in panels $40.00

33. Power Mania shore battery charger under front passenger seat, works when plugged into shore power, 30 amps per battery $286.00

34. Shore power 110V plug mounted inside, hot when connected to shore like an RV $20.00

35. 600 watt inverter $299.00

36. SCT turner, used to correct speedo $399.00

37. Black Berry blue tooth module to connect music to stock radio $49.00

38. Ham antenna $39.00

39. Wheel Skins leather steering wheel cover $69.95

40. (3) Bussman circuit breakers $75.00

41. Wire used for build $419.00

42. Rear USB port and temp gauge $50.00

43. (2) Blue Sea fuse panels $80.00

44. Poop shovel $16.00 (Cuz it happens) :)

45. Phillips Crystal vision headlight bulbs hi/lo $100.00

46. Traction board pins/mounts $39.99

47. OEM Ford workshop manuals $130.00

48. Stan Sport front radiator grill $50.00

49. LED Back up bulbs in stock tail lights $25.00

50. New LED rear third brake light red $39.00

51. Floor Matts $59.99

52. 2 key fobs

53. Alternator 250 AMP high output $399.00

54. (2) 100 amp hour Battle Born batteries for a total of 200 amp hours to run fridge and camping equipment $2000.00

55. Yellow Top Optima AGM battery for the start battery $286.00





Total cost of overlanding parts $60,133.78

Total cost of mechanical parts replaced or updated $7165.40

Labor for the build $23,000.00

Truck cost $12,500.00



To duplicate this truck, IF you can get the parts we did, would cost $102,787.78, truck price as outfitted for only $53,000.00
