Show your Lifted 3rd Gens

[jered]

ok, sorry i dont know the correct term, it has electric suspension, 3 modes to choose, sport normal and comfort. Can i still lift it?



[LokiWolf]

ok, sorry i dont know the correct term, it has electric suspension, 3 modes to choose, sport normal and comfort. Can i still lift it?

OH, Your KR has CCD! That is completely different. You have electrically controlled shocks. It affects the dampening.

No, without completely removing them, you cannot lift it.


Sent from my iPhone using Tapatalk Pro



[jered]

dang, would it throw error messages in the dash to take them off



[LokiWolf]

sorry, it has electronic suspension control. can I lift it?

Answered above...


Sent from my iPhone using Tapatalk Pro



[BBenson]

Right on the $$. Next tire I need tires I’ll be dropping the spacers and going somewhere between +10 and +18

I saw you have 11.5 wide tires, do you know if 12.5 will fit? I am trying to figure out how wide I can go, or should go. I know 11.5 limits your wheel selection. I was thinking of maybe going 285-75-17, what do you think?



[16plati]

I saw you have 11.5 wide tires, do you know if 12.5 will fit? I am trying to figure out how wide I can go, or should go. I know 11.5 limits your wheel selection. I was thinking of maybe going 285-75-17, what do you think?

285/75/17 should fit no problem if it’s a +44 offset. If you want the look I have you’ll need 1.25” spacers or a +12 offset wheel. I went the spacer route until my wheels become ****** and I’m tired of how they look. Anything more negative than +12 will require quite a bit of trimming. I had to trim 1” of the front bumper and move my electronic running boards back to fit the 35/11.50/20 +44s with 1.25” spacer. (Which would equate to a 35/11.50/20 on +12s)



[BBenson]

285/75/17 should fit no problem if it’s a +44 offset. If you want the look I have you’ll need 1.25” spacers or a +12 offset wheel. I went the spacer route until my wheels become ****** and I’m tired of how they look. Anything more negative than +12 will require quite a bit of trimming. I had to trim 1” of the front bumper and move my electronic running boards back to fit the 35/11.50/20 +44s with 1.25” spacer. (Which would equate to a 35/11.50/20 on +12s)

We are on the same page. I am just wondering if you could fit 35/12.5/20 without rubbing on the inner fender well or anywhere else, or if 11.5 width is about the widest you think you can go with the current offset and conditions.



[16plati]

We are on the same page. I am just wondering if you could fit 35/12.5/20 without rubbing on the inner fender well or anywhere else, or if 11.5 width is about the widest you think you can go with the current offset and conditions.

If I put 12.50 wides on I would have a lot more cutting and rubbing to deal with. Would rub all over the front bumper, inner wheel liners, UCAs and running boards with setup i have now



[Dannyboy11222]

OK my turn.. What about 285/60/r20 on a on a rim with a +30 offset... Without any mods?

Sent from my LM-G710VM using Tapatalk



[16plati]

OK my turn.. What about 285/60/r20 on a on a rim with a +30 offset... Without any mods?

Sent from my LM-G710VM using Tapatalk

I would have to take a look at my wife’s stock limited and take some measurements. Overall you will gain 3/4”of height per side over stock 275/55/20 (I’m assuming thats what you had stock) and about .20” each side width wise. Then your adding the .5” for the difference in +44 and +30 to overall distance from hub for a total of

3/4” height
~3/4” width

I would bet that would be ok. I can try to take measurements tomorrow on my wife’s to see how much room there is stock
