05 expy service manual needed

[Spider45]

Anyone have access to the manual for 05 expys? Specifically the wiring diagrams for the lights. Digital form would help or fax some pages.
Bob Webb 407-469-5575
Trying to find if there is a relay connection for the fog lamps or is it electronic. On my 03 sportrac I was able to cut a relay leg off and keep the fogs on with the hi beams. Sweet

Thanks in advance!!!

05x w/tow
K&N CAI
Next: Sniper tune



[ELVATO]

Do you think the wiring would be anything like the 03s? If so, Id be willing to scan part of manual.

As a side note, Id like to know how to wire my fogs to run with the hi beams



[Spider45]

Manual needed

You have to check the electrical drawings. But try the SportTrac users forum site. I think it's Mysporttrac.com. One or 2 T's. There should still be a post about it there. Relays are cheap so do it during the day and if it doesn't work, replace the relay. Buy the relay first. you can always return it.
On the Sport the relays are in the engine compartment on the left.

I guess I could follow my own advice and buy a spare relay. DOH



[Spider45]

It would be nice if you could scan the pertinent pages that deal with the switch, relay and lamps. I could then trace the voltage through the empty relay socket to see. Might be different on the 05 tho.
If you want to , pls fax to 407-469-5574 attn: Bob Webb



[ELVATO]

Sorry for taking so long. Heres some pix of the power distribution diagram and the list of fuses and relays. Hope this helps Sorry that they're sideways
