02 Autoheadlight Dillema!

[5.4T]

Hey, so I had my navigator for 3 years now and I could never get the interior lights to come on at night. Only the headlights come on but everything else is off.I've checked all the fuses in the Drivers kick panel and under the hood nothing! I also messed with the sensor Located on the top of the dash, took it apart and everything but im guessing that one only controls the headlights so wheres the one that controls the Interior lights?Are there any other fuses some where else?This is been Driving me crazy!!!!



[JUST4FUN]

I'm not sure mabey stamp can clear this up .but did this have a lighting control modual? Also some of the lighting went through the multifunction swich



[5.4T]

Well my brother has an expedition and I switch the light switch with mines and that didn't do nothing. I'm guessing it does have a lighting control modual?



[stamp11127]

My manual is for a 99 but the logic may be the same. Will the interior lights come on when you open the door(s)?



[5.4T]

yes. I got Leds



[5.4T]

Exterior

Autolights ON, as you can see the rear lights dont turn on!



Autolights ON Corner light are not on!

Interior

Autolights ON Cluster,radio climatecontrol all off ect.


Autolights OFF Interior light are on w/ headlight switch on ON



P.S. truck was not on that's why all the idiot lights are on


Temple Ga ? if you ever in Atl let me know



[stamp11127]

I'm going to make an assumption here. The only thing that changed was replacing the dash lights with LEDS. No other mods were made and the dash lights did work prior to the change. Is that correct?



[stamp11127]

Also check the parking lamp relay operation.

Do you have a test light or dvm?



[bedrck46]

auto lamp circuit

see attached prints Hope these help



[5.4T]

I'm going to make an assumption here. The only thing that changed was replacing the dash lights with LEDS. No other mods were made and the dash lights did work prior to the change. Is that correct?

no they didn't work even before the Leds but I do have a test light.

see attached prints Hope these help

On the 87-1page, where it said hot to start or run in the Central Junction box the 16 29 5A 31 inside the box, Are those suppose to be Fuses?

Thank you for the diagrams



[bedrck46]

fuse

The numbers can be confusing to make it simple its fuse #29 and its 5amp the other numbers are just wire numbers



[stamp11127]

Bedrck46, any chance you would also post the pages for the instrument illumination and for testing the main light switch?



[bedrck46]

prints

let me know if you need anything else will send more on next post



[bedrck46]

prints also

only one



[stamp11127]

Yep need more:
all of sections 71 and 149 please



[bedrck46]

will take some time to send them total of 32 pages and can only send 5 at a time or send me your e-mail addy might be easier that way



[FordCustSrvc]

Hey, so I had my navigator for 3 years now and I could never get the interior lights to come on at night. Only the headlights come on but everything else is off.I've checked all the fuses in the Drivers kick panel and under the hood nothing! I also messed with the sensor Located on the top of the dash, took it apart and everything but im guessing that one only controls the headlights so wheres the one that controls the Interior lights?Are there any other fuses some where else?This is been Driving me crazy!!!!

Hey 5.4T,

I recommend heading over to your Ford/Lincoln Dealer for diagnosis. You may locate one and schedule an appointment here.

Have a great weekend.

Todd



[5.4T]

GOT IT FIXED!!! ty all it ended up being the brown/white wire in the headlight switch



[bedrck46]

glad you got it working
